Cut-Dimension Drift Sampling Plan
Repeated cuts can begin within tolerance and drift later as a stop moves, debris accumulates, stock changes, a blade heats, or the measurement method changes. A sampling plan defines which dimensions are checked, how often they are checked, what limit stops production, and how suspect parts are contained. It is not a substitute for guarding, safe machine use, or a verified first article; it is the control that keeps an accepted setup accepted through the batch.
Target keywords
Choose the dimensions that deserve sampling
Prioritize dimensions that control assembly, reveal, hardware fit, joint engagement, or equality across a visible run. Include a reference edge or squareness check when the process can introduce taper. Cosmetic dimensions with generous trim allowance may need fewer checks, while drawer-box width, paired doors, shelves in one opening, and parts cut from one stop usually deserve tighter observation.
Set the opening and closing checks
Measure the first accepted parts before production count begins and retain their recorded values as the setup baseline. Measure the final parts before the setup is removed. These bookend checks prove only the ends of the run, so add interval checks based on batch size, material variability, and the cost of a hidden error. The crosscut release checklist provides a concrete setup boundary.
Use a trigger-based interval
Check after a defined quantity and whenever the blade, fence, stop, operator, material batch, support method, or reference face changes. Also check after a jam, impact, unusual vibration, debris cleanup, or interruption long enough that the setup could have moved. A fixed every-tenth-part rule is easy to remember, but it should become more frequent when process risk or remake cost is high.
Record observations, not only pass marks
Write the actual measured result, part IDs covered by the interval, measurement tool, unit, target, and acceptance range. A row of check marks cannot reveal gradual movement toward the limit. Use one measurement method and stable reference points so operator technique does not look like machine drift. The kerf definition helps separate blade-width assumptions from a changing finished dimension.
Contain parts after a failed sample
Stop the setup and identify every part made since the last accepted check. Segregate that interval instead of mixing it with accepted work. Diagnose the cause, correct the setup, verify a new first article, then measure or disposition the suspect parts. The repeat-cut drift diagnostic distinguishes moving stops, reference errors, stock variation, and technique problems.
Close the batch with evidence
Compare the first, interval, and final measurements for a trend even when every point passed. Record rework, remake, and scrap against part IDs, then preserve the accepted values with the cut-list revision. When repeated rectangles must be laid out again, update the quantities in CutList rather than hiding replacement parts in an informal note.
